How to connect Bria solo (X-lite) to Sonetel

Bria solo (formerly X-lite) is a popular 3rd party SIP phone that can be connected to Sonetel for making and receiving calls. It works with Windows and Mac.

Here are the instructions for how to connect Bria Solo to Sonetel.

1. Start
   Log in to your Bria Web Portal
2. Click on the Phone icon or Voice and Video option at the top of the screen
3. In the Add Voice Service screen, click on Configure SIP Settings
4. Fill in these details on the General Tab
   1. Service label
      Enter Sonetel (or any name to easily identify the Sonetel account)
   2. Domain
      Enter the second part of your email address. For example, if your email address is “joe@company.com” enter “company.com“
   3. Port
      5060 (or leave blank)
   4. SIP Username/Call Extension
      Enter the first part of your email address. For example, if your email is “joe@company.com” enter “joe“
   5. Password
      Enter the user’s Sonetel password.
   6. Authorization username
      Enter the same as in SIP Username (see above)
5.  In the Service Settings Tab, configure the following:
   1. SIP Settings:
      1. SIP Proxy
         Enter sip.sonetel.com
      2. Tick mark “Register with domain and receive calls”
      3. Transport
         Select UDP
      4. Registration Time:
         300
      5. RPORT
         Enabled
      6. Keep Alive
         Enabled
   2. Firewall:
      1. Method
         Select STUN
      2. Firewall Server URL
         Enter stun.sonetel.com
   3. Service Options:
      Tick mark “Force outbound proxy on all requests”
6. Save your settings

Once you’ve saved your settings, the final step is to synchronize your Bria app. Launch the Bria app and sign in using your Bria account credentials. This will automatically sync your newly configured Sonetel account details. If you’re already logged into the Bria app, simply sign out and then sign back in to ensure the new Sonetel settings are properly synchronized.
